1543253C1 Lift Ldr Tilt Grapple Cylinder Seal Kit Fits Case 480C 480D 480E 480F

One New Aftermarket Replacement Loader Lift Tilt Grapple Hydraulic Cylinder Seal Kit




Fits Case Loader/ Backhoe


Application: Loader Lift, Loader Tilt
Models: 480C, 480D, 480 LL, 480E, 480E LL

Application: Loader Bucket
Model: 480F 480F LL
Cylinder: G101186

Application: Loader Tilt
Model: 580 Super E, 580C, 580D, 580 Super D, W11, W11B
Model: 350B with Backhoe Models 26C, 26D

Application: Loader Grapple
Model: 580C

Tech Info:
ROD: 1.50″
BORE: 2.50″


1 Piece Piston Press In Wiper Rod Seal Type: U-Seal & Buffer Piston Seal Type: Piston Seal

Models This Part Fits:

350, 350B, 480, 480C, 480D, 480D LL, 480E, 480E LL, 480ELL, 480F, 480F LL, 480LL, 580 SUPER D, 580 SUPER E, 580 Super D, 580 Super E, 580B, 580C, 580D, 580E, 580F, 580SD, 580SE, 680C, MB4, Super D, Super E, W11, W11BAdditional Information: Rod Diameter: 1 1/2″Tube Bore Size: 2 1/2″

Reference Numbers:

1543253C1, 1543253C1-A, 1543253c1, 1543253c1-A, 480D-480E-LL-LB, 480D-480E-LL-LB-A, 580D-E-SD-SE-LB, 580D-E-SD-SE-LB-A
