RE29878 Disc Pulley Overhaul Clutch Kit Fits John Deere 50 520 530 Repair Set

(1) New Aftermarket Replacement Disc Pulley Clutch Kit

Fits John Deere Models: 50, 520, 530

Kit Includes:
1 Pulley Clutch Discs w/Bonded Lining (RE29878)
2 Floating Clutch Facing Discs (B2354R)
1 Belt Pulley Brake Pad Lining (RE29790)
3 Clutch Disc Adjusting Springs (B161R)
3 Clutch Adjusting Nuts (14H994)
3 Clutch Pressure Plate Spring (Fits Belleville) Washer (Fits JDS1626)

Replaces Part Numbers: RE29878, B2354R, RE29790, B161R, 14H994, Fits JDS1626

Models This Part Fits:

520, 530Additional Information: Kit Contains:(1) Pulley Clutch Discs w/ Bonded LiningIncludes Riveted Lining0.445″ Thick1-1/2″ Lining WidthReplaces Part Number(s):AB3471R, B2355R, AB4828R, RE29878(2) Floating Clutch Facing Discs7″ OD x .160 ThickReplaces Part Number(s):R90220(1) Belt Pulley Brake Pad LiningWovenNon-Asbestos Lining with Countersunk Brass RivetsReplaces Part Number(s):AB4748R, AF4748R, RE29790(3) Clutch Disc Adjusting SpringsIt Mounts to the Outer Cast Iron Adjusting DiscReplaces Part Number(s):B161R(3) Clutch Adjusting Nuts1/2″ – 20 NfGrade 5ZincSlotted Hex Nut, 1/2″3 Used Per TractorReplaces Part Number(s):B3279R, AA4967R, A335R, 14H994(3) Clutch Pressure Plate Spring (Belleville) Washer0.572″ Inside Diameter0.937″ Outside Diameter0.035″ ThickSpring SteelTorque Initially to 15 Ft Pounds, Then Adjust as NeededUse to Smooth Out the Hand Clutch Engagement3 Used Per TractorReplaces Part Number(s):AR21803R, R21647

Reference Numbers:

14H994, B161R, B2354R, JDS1626, RE29790, RE29878
